UNC Fluteless Roll Form Taps (Forming Taps) | Guhring
UNC Fluteless Roll Form Taps (Forming Taps) | Guhring
UNC Fluteless Roll Form Taps (Forming Taps) | Guhring

UNC Fluteless Roll Form Taps (Forming Taps) | Guhring

by Guhring
$95.34 - $248.28
$95.34
$95.34 - $248.28
$95.34

Engineered for high-efficiency thread production with zero chip generation, the Guhring UNC Fluteless Roll Form Tap range represents the ultimate solution for high-volume automated manufacturing. Operating on a material displacement mechanism rather than traditional metal cutting, these premium UNC forming taps cold-forge the metal substrate to produce internal threads with significantly higher tensile strength and flawless surface finish quality. Because they completely eliminate chip packing, they are the definitive industrial choice for deep blind holes where chip extraction is a constant risk. Available with specialized lube grooves for optimal high-pressure cooling, Guhring's fluteless series delivers unmatched tool life and rapid cycle speeds when threading ductile materials, including structural aluminum alloys, brass, copper, low-carbon mild steels, and malleable stainless steels in modern CNC environments.

    TECHNICAL DATA

    • Made from High Speed Steel
    • Standard  - DIN 371 / DIN 376
    • Tolerance - 2BX
    • Surface - TiCN Coated
    • Guhring No. 4491
